Refrigerated Compressed Air Dryer

Energy Savings

High efficiency heat exchanging wings made of aluminum alloy plates, cross-flowing high efficiency heat exchanging and sufficient exchanging area, maximizing the cooling energy inside the machine. Pressure loss is less than 0.02MPa.

Enviromental Friendly

Aluminum-alloy-made heat exchangers never get rusted, strong anti-corrosion property, pollution reoccurrence free. Environmental cooling medium adopted across the series, keeping up with the international trends of environment protection.

Excellent Performance

Under nominal operation conditions, the outlet dew point is 3􀂥 lower than that of the conventional tube shell refrigerated compressor air dryer..

Top Configuration

Whole series of refrigerated compressors are of first class brands. Whole series of refrigeration control elements are of first class brands. Whole series of air coolers adopt nanometer anti-corrosion coating on the surfaces. Packed with Y-shape air inlet filters to effiectively reduce pipe pollutants on the heat exchanging channel.

Compact

The high efficiency heat exchangers made of aluminum alloy plates are, under same flow capacity, 2/3 less in volume than that of the conventional tube shell exchangers. The layouts are more compact, significantly reducing the footprint of the equipments, further freeingcustomers’ limited space.
