Compressed AIr Treatment Equipment

We offer a high-quality Air Receiver Tank made of galvanized steel with a storage capacity of 1000-1500L. Designed for air storage, this vertical tank has a max working pressure of up to 40 kg/cm2. Originating from India, our tank is ideal for various applications. As an Exporter, Supplier, and Trader, we provide reliable and durable air storage solutions to meet your industrial needs.

Inlet pressure: 6 ~ 10bar

Pressure dew point: -70~ -40

Purge air: 3 ~ 5%

Pressure drop < 0bar

Features

• Liquid separator filter (C): 3 micro, 5 ppm
• Particulate filter (T): 1 micro, 1 ppm
• Oil removal filter (A): 0.01 micro, 0.01 ppm
• Oil removal extra fine filter (AA): 0.01 micro, 0.001 ppm
• Vapor filter (H): 0.01 micro, 0.001 ppm

We provide a durable and long-lasting Oil / Water Separator designed for efficiency. With an inlet pressure range of 2 ~ 10 Bar and a 5 µm filter route, our separator ensures optimal performance. Operating at temperatures between 6 ~ 65°C, it boasts a water removal rate of ≥99% and an initial pressure drop of ≤0.005 MPa. Ideal for manufacturers and suppliers, this separator guarantees reliable separation of oil and water, making it a valuable asset for your operations.

We are a leading Manufacturer and Supplier of high-quality Desiccant Air Dryer from India. Our fully automatic electric air dryer, with a power range of 1-3kw and voltage of 440V, efficiently removes vapor. Weighing between 150-200kg, this top-notch dryer is designed for industrial applications. Trust our reliable product for superior performance and durability in maintaining optimal air quality. Choose our Desiccant Air Dryer for effective moisture control and peace of mind in your operations.

The nitrogen generator consists of two main adsorption towers. When clean compressed air enters the inlet of Tower A and flows towards the outlet through carbon molecular sieves, O2, CO2, and H2O are adsorbed by them, while the nitrogen product flows out from the outlet of the adsorption tower. After a period of time, the carbon molecular sieves in Tower A become saturated with adsorbed gases. At this point, Tower A automatically stops adsorption, and compressed air flows into Tower Bfor oxygen adsorption and nitrogen production, while Tower A's molecular sieves undergo regeneration.

PSA oxygen production employs high-quality oxygen molecular sieves as adsorbents. It operates by pressurized adsorption and atmospheric pressure desorption to separate oxygen and nitrogen in the air and extract oxygen.

The adsorbent used in PSA oxygen production is zeolite molecular sieve, which is a polar adsorbent composed of a framework of positively charged cations and negatively charged silicon-aluminum-oxygen. Although O2 and N2 are non-polar adsorbates, the influence of polar molecules in zeolite molecular sieve induces a force. Since the induction force of N2 is greater than that of O2, the adsorption capacity of zeolite molecular sieve for N2 is much higher than for O2.

When air passes through the zeolite molecular sieve, N2 is preferentially adsorbed by the zeolite molecular sieve and enriched in its micropores, while O2, except for a small amount, mostly passes through the zeolite molecular sieve to become product oxygen. As zeolite molecular sieve is a polar substance, the stronger the polarity or the easier the polarization of the molecule, the easier it is to be adsorbed. Therefore, substances in the air such as acids, bases, carbon dioxide, oxides, halogens, etc., which are highly polar molecules, naturally find it difficult to enter the product oxygen through the zeolite molecular sieve.

Energy Savings

High efficiency heat exchanging wings made of aluminum alloy plates, cross-flowing high efficiency heat exchanging and sufficient exchanging area, maximizing the cooling energy inside the machine. Pressure loss is less than 0.02MPa.



Enviromental Friendly

Aluminum-alloy-made heat exchangers never get rusted, strong anti-corrosion property, pollution reoccurrence free. Environmental cooling medium adopted across the series, keeping up with the international trends of environment protection.



Excellent Performance

Under nominal operation conditions, the outlet dew point is 3􀂥 lower than that of the conventional tube shell refrigerated compressor air dryer..



Top Configuration

Whole series of refrigerated compressors are of first class brands. Whole series of refrigeration control elements are of first class brands. Whole series of air coolers adopt nanometer anti-corrosion coating on the surfaces. Packed with Y-shape air inlet filters to effiectively reduce pipe pollutants on the heat exchanging channel.



Compact

The high efficiency heat exchangers made of aluminum alloy plates are, under same flow capacity, 2/3 less in volume than that of the conventional tube shell exchangers. The layouts are more compact, significantly reducing the footprint of the equipments, further freeingcustomers’ limited space.

Features

• Liquid separator filter (C): 3 micro, 5 ppm
• Particulate filter (T): 1 micro, 1 ppm
• Oil removal filter (A): 0.01 micro, 0.01 ppm
• Oil removal extra fine filter (AA): 0.01 micro, 0.001 ppm
• Vapor filter (H): 0.01 micro, 0.001 ppm
